MSI IPC
MSI IPC delivers efficient DMS (Design & Manufacturing Services) solutions for embedded and industrial.
Supports Intel Raptor Lake-S Core Processors, LGA 1700
Quad Display via 2 x DP, 2 x HDMI, or LVDS/eDP
PCI-E 5.0 x16 slot, 16-bit GPIO header
3 x Intel RJ45 2.5GbE LAN, M.2 2230 slot for WIFI
Mini ITX: 6.7" x 6.7", Onboard TPM 2.0
Supports AMD EPYC 9005 Processors, Socket SP5
Liquid Cooled CPU, 12 x 2.5" NVMe Drive Bays
4 x PCI-E 5.0 x16 slots (FH, FL, Double Width)
Dedicated Mangement LAN
4U Server: 17.2" x 6.9" x 32.6"
Quad Display via 2 x DP, HDMI, or LVDS/eDP
PCI-E 4.0 x16 slot, 16-bit GPIO header, 2 x Powered COM
Intel Core i5-1345UE Processor
HDMI Quad Display Max Resolution: 4096x2340@60Hz
4 x COM, 8-Bit GPIO, Wide Voltage DC-IN
4 x Intel I226-LM GbE LAN, M.2 2230 slot for WIFI
Fanless Industrial PC: 8.5" x 6.1" x 2.6"
Intel Alder Lake N97 Quad Core Processor
Triple Independant Displays: DP, LVDS/eDP
M.2 B Key with SIM Holder for LTE
2 x 2.5GbE LAN, M.2 2230 slot for WIFI
Fanless Mini ITX: 6.7" x 6.7", Onboard TPM 2.0
Supports Intel 14th Gen Processor, Raptor Lake-S
Triple Display via DisplayPort, HDMI, VGA
2 x PCI-E 5.0 x16 slot, 3 x PCI-E 3.0 x4 slots
ATX: 12" x 9.6", Onboard Infineon TPM 2.0
Supports Dual AMD EPYC 9005/9004 Processors, Socket SP5
4 x 3.5" NVMe, 8 x 3.5" SATA, 2 x M.2 2280 slots
3 x PCI-E 5.0 x16 slots (FH, FL, Double Width), 1 x OCP 3.0 slot
2 x Intel GbE LAN, Dedicated Mangement LAN
2U Server: 17.2" x 3.4" x 30.3"
12 x 2.5" NVMe Drive Bays, 2 x M.2 2280 slots
2 x PCI-E 5.0 x16 slots (HH, HL), 1 x OCP 3.0 slot
1U Server: 17.2" x 1.7" x 30.3"
Supports AMD EPYC 4004 or Ryzen 7000 Processors, Socket AM5
4 x 3.5/2.5" SATA Drive Bays, ECC/Non-ECC Memory
PCI-E 4.0 x16 slot (FHHL), 1+1 450W 80+ Platinum Power Supply
2 x Intel X710AT 10G LAN, Dedicated Mangement LAN
1U: 17.26" x 1.71" x 21.56"
Supports Intel Xeon E-2400 Processor, LGA 1700
4 x SlimSAS 4i, ECC/Non-ECC Memory
PCI-E 5.0 x16 slot, PCI-E 4.0 x8 slot
2 x Intel SFP28 25G LAN, Dedicated Managemenet LAN
Micro ATX: 9.6" x 9.6"
Supports EPYC 4004 or Ryzen 7000 Series Processors, AM5
ECC/Non-ECC Memory
2 x Intel 1G LAN, Dedicated Managemenet LAN
2 x Intel 10G LAN, Dedicated Managemenet LAN
2 x SlimSAS 4i Connectors for NVMe and 4 x SATA
2 x RJ45 GbE LAN, 1 x Dedicated Management LAN
4 x SlimSAS 4i Connectors for 4 x NVMe or 8 x SATA
2 x RJ45 10G LAN, 2 x RJ45 GbE LAN, 1 x Dedicated Management LAN
Supports Intel Raptor Lake-S Core i3 Processors
Quad Display via HDMI, or LVDS/eDP
M.2 2242/3042 slot with Nano SIM Holder
4 x Intel RJ45 GbE LAN, M.2 2230 slot for WIFI
3.5" SBC: 5.75" x 4.01" , Onboard TPM 2.0
Supports Intel Raptor Lake-S Core i5 Processors
3.5" SBC: 5.75" x 4.01", Onboard TPM 2.0
Intel Alder Lake Core i3 8-Core Processor
Triple Independant Displays: DP, HDMI, LVDS/eDP
Intel Celeron Elkhart Lake J6412 Quad Core Processor
Dual Display via HDMI
Wide Operating Temp with WT devices
2.5G LAN, Powered COM, GPIO
Fanless Industrial PC: 5.12" x 6.10" x 1.57"
Intel Alder Lake-N N97 Processor
Dual Display via HDMI, DisplayPort
2 x COM, 2 x Optional COM/CANbus, 6 x USB 2.0
2 x Intel I225-V 2.5GbE LAN, M.2 2230 slot for WIFI
Fanless Industrial PC: 7.87" x 5.9" x 2.2"
Triple Display via DisplayPort, HDMI
PCI-E 5.0 x16 slot, 1 x PCI-E 3.0 x4 slots
4 x 2.5GbE LAN, M.2 2230 slot for WIFI
Micro ATX: 9.6" x 9.6", Onboard Infineon TPM 2.0
Quad Display via DisplayPort, HDMI
PCI-E 5.0 x16 slot, 2 x PCI-E 3.0 x4 slots, PCI-E 3.0 x1 slot
2 x PCI-E 5.0 x16 slot, 3 x PCI-E 3.0 x4 slots, PCI-E 3.0 x1 slot
Intel Alder Lake-N Atom x7245E 4-Core Processor
Triple Display via DisplayPort, HDMI, LVDS/eDP
M.2 2280/3042 slot for SSD or Modem Expansion
2 x Intel 2.5GbE LAN, M.2 2230 slot for WIFI
3.5" SBC: 5.75" x 4.02", 4-Pin Wide Voltage DC-IN
Intel Alder Lake-N Core i3-N305 8-Core Processor
Intel Alder Lake-N N97 Quad Core Processor
Triple Display via 2 x DP, HDMI, or LVDS/eDP
2 x Intel RJ45 2.5GbE LAN, M.2 2230 slot for WIFI
