Hardware Based Security
TPM
Trusted Platform Modules. Enhance the security of computers with securely stored cryptographic keys for encryption and descryption.
Configure a solution
ASRock Trusted Platform Module (TPM)
Nuvoton NPCT650
Supported on H110, X299, AM4, TR4 Platform Motherboards
Vertical Orientation Compatible with Supermicro X11 motherboards with 10-pin TPM header
TCG 2.0 Compliant Trusted Platform Module (TPM)
EEPROM for TCG firmware enhancements and for user data and keys
Hardware accelerator for SHA-1 and SHA-256
Random Number Generator (RNG)
Meeting Intel TXT, Microsoft Windows and Google Chromebook certification criteria
Supermicro AOM-TPM-9665V Trusted Platform Module (TPM 2.0)
Infineon 9665 Chipset
ASRock TPM 2.0 14-1 Pin, SPI Interface
Random Number Generator (RNG) according to NIST SP800-90A
Full personalization with Endorsement Key (EK) and EK certificate
Microsoft Windows and Linux kernel v2.6.18 and higher
Intel-based LPC Host Interface
Physical Presence Detection
GPIO operated by TCG Commands
Compatible with ASRock IPC, Rack and commercial motherboards
ASUS TPM 2.0 14-1 Pin, SPI Interface
Chip: Nuvoton NPCT750
Common Criteria EAL4+ Certified
FIPS 140-2 Certified
CE and RoHS Compliance
Gigabyte CTM000 TPM 2.0 Module
Infineon SLB9665TT2.0 Controller
Low Pin Count Interface, 2 x 7 Pin
Dimensions: 20 x 15mm
Supermicro AOM-TPM-9665V-C Trusted Platform Module (TPM 2.0)
Supported CPUs Core i7/i5, Xeon E3
Compatible with Supermicro X11 motherboards with 10-pin TPM header
Tyan TPM 2.0 11 Pin, SPI Interface
Chip: Infineon
TCG 2.0 compliance
RoHS Compliance
Gigabyte 25CRZ-100600-S9R Cable
Compatible with Gigabyte Low Pin Count TPM 2.0
Supports Intel Rocket Lake Xeon E-2300 Processors, LGA 1200
Maximum 64GB DDR4 ECC UDIMM Memory
2 x Intel RJ45 1GbE LAN, Dedicated IPMI LAN port
PCI-E 4.0 x16 slot, 1 x Mini-SAS-HD, M.2 2280 slot M-key
Mini ITX Form Factor, TPM 10-1 pin Header
Includes 25CRZ-100600-S9R Cable
