Manufacturer	Supermicro
Part Number	X11SBA-LN4F
CPU	Intel Pentium N3710 Processor 4 Cores / 4 Threads 1.60 - 2.56 GHz 6W TDP, 2 MB L2 Cache
Chipset	SoC
Memory	2 x DDR3 SODIMM slots Maximum 8GB Capacity 1600/1333/1066 MT/s
Video	ASPEED AST2400 BMC Intel HD Graphics 400 - 700 MHz
Audio	Realtek ALC888S
Storage Technology	2 x SATA Ports
Connectivity	4 x Intel I210-AT GbE LAN 1 x Intel Realtek RTL8211E GbE Dedicated IPMI
Expansion Slots	1 x PCI-E 2.0 x1 slot (x8 size) 1 x Mini PCI-E with mSATA Support
Power	1 x 24-Pin ATX Power Connector Alternate 12V 4-Pin ATX Power Connector
Rear I/O	1 x DisplayPort 1 x HDMI 1 x RJ45 GbE Dedicated IPMI 2 x USB 2.0 2 x USB 3.0 4 x RJ45 GbE LAN 1 x COM 1 x VGA
Onboard I/O Headers	4 x USB 2.0 header 1 x Audio Front Panel header 2 x COM headers 1 x General Purpose I/O header 1 x External Speaker header 1 x Front Panel Control header 1 x 4-Pin BMC External I2C header 1 x Chassis Intrusion header
OS Support	Windows 10
Form Factor	Mini ITX 6.7" x 6.7" 170 x 170mm
Environmental	Operating Temperature: 0°C to 60°C (32°F to 140°F) Non-Operating Temperature: -20°C to 60°C (-4°F to 140°F) Operating Humidity: 10% to 85% (non condensing) Storage Humidity: 10% to 95% (non condensing)
Warranty	1-Year Manufacturer's Limited Warranty
