| Manufacturer | Supermicro |
| Product ID | SYS-111AD-HN2-01-G2 |
| Motherboard Model | Super X13SAZ-F |
| CPU | 1x Intel® Core™ i7-12700E (12C/2.1GHz) (INCLUDED) Supports Intel Core 3/5/7 (Series 2) and 14th/13th/12th Gen Core i3/i5/i7/i9 Up to 12C/20T |
| Memory | 64GB DDR5-5600 (INCLUDED) 4 x DDR5 DIMM slots Maximum 128GB Capacity, 4400MT/s ECC/non-ECC UDIMM |
| Video | 1 x VGA Port 1 x DVI-D Port 2 x DisplayPort 1.4 1 x HDMI 2.0b (4K@60Hz) |
| Storage Technology | 2 x 1.92TB 2.5" SATA SSD (INCLUDED) 1 x M.2 NVMe Slot (2280/22110) SATA 6Gb/s |
| Connectivity | 1 x Dual 2.5GbE RJ45 (Intel® I225-LM) 1 x Dedicated 1GbE BMC LAN |
| Rear I/O | 4 x USB 3.2 (Gen2) Type-A 1 x VGA 1 x DVI-D 2 x DisplayPort 1.4 1 x HDMI 2.0b Line Out / Mic In |
| Drive Support | 1 x M.2 NVMe Slot (M-Key 2280/22110) |
| Power Supply | 1 x 200W Gold Level (91%) Power Supply |
| Cooling | Up to 4 x 4-Pin PWM 40x28mm Fans 1 x Air Shroud |
| Case Dimensions | 1U Rackmount Form Factor 437 x 43 x 287mm 17.2" x 1.7" x 11.3" (in inches) |
| Environmental | Operating Temperature: 0°C to 40°C (32°F to 104°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Operating Humidity: 8% to 90% (Non-Condensing) Non-operating Humidity: 5% to 95% (Non-Condensing) |
| Weight | Net Weight: 10 lbs (4.54 kg) Gross Weight: 14.1 lbs (6.4 kg) |
PRODUCT ID: SYS-111AD-HN2-01-G2
