| Manufacturer | Supermicro |
| Product ID | SYS-1019D-FRN8TP |
| CPU | Intel Xeon D-2146NT Processor 8 Cores / 16 Threads 2.30 - 3.00 GHz 80W TDP, 14nm, 11 MB Cache |
| Chipset | SoC |
| Memory | 4 x DDR4 DIMM slots Supports ECC RDIMM/LRDIMM Supports 2666/2400/2133 MHz Operating up to 2133 MHz Supports up to 512GB ECC LRDIMM Supports up to 256GB ECC RDIMM |
| Video | Aspeed AST2500 BMC |
| Storage Technology | 12 x SATA3 6Gb/s Ports Supports RAID 0, 1, 5, 10 1 x M.2: PCI-E 3.0 x4 (2280) 1 x M.2: SATA/PCI-E 3.0 x2 (2242) |
| Connectivity | 2 x SoC 10G SFP+ Ports 2 x 10GBase-T Ports 4 x Intel I350-AM4 GbE LAN 1 x Realtek RTL8201N PHY Dedicated IPMI |
| Expansion | 1 x PCI-E 3.0 x16 slots (Full Height, Full Length) 1 x Mini PCI-E x1 slot 1 x M.2 slot (B-Key, 2242) |
| Front Panel I/O | 5 x Status LED (Power, HDD, LAN, System) 1 x Reset Button 1 x Power Button 1 x RJ45 (Dedicated IPMI) 2 x USB 3.0 2 x 10GBase-T RJ45 4 x RJ45 GbE LAN 2 x 10G SFP+ Ports 1 x VGA |
| Drive Support | 1 x M.2 slot (2280, M-Key) 4 x 2.5" Internal Fixed Drive Bays |
| Power Supply | 350W 80 PLUS Platinum Power Supply with PFC 100-240V, 50-60Hz, 4.2-1.8A Max |
| Cooling | 4 x 40x56mm Fans |
| Case Dimensions | 1U Form Factor 429 x 437 x 43mm 16.9" x 17.2" x 1.7" (in inches) |
| Environmental | Operating Temperature: 10°C to 40°C (50°F to 104°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Operating Humidity: 8% to 90% (non-condensing) Non-operating Humidity: 5% to 95% (non-condensing) |
| Compliance | RoHS |
| Warranty | 1 Year Manufacturer's Limited Warranty on Parts 3 Year Manufactuere's Limited Warranty on Labor |
PRODUCT ID: SYS-1019D-FRN8TP
