Manufacturer | ASUS |
Product ID | RS720A-E13-RS12U-27KW10G |
Model Number | RS720A-E13-RS12U |
CPU | Supports 2 x AMD EPYC 9005 Series processors Socket SP5 Up to 400W TDP |
Chipset | SoC |
Memory | 24 x DDR5 DIMM slots (12 per CPU) DDR5 6400/5600 RDIMM/3DS RDIMM Maximum 3072GB Capacity |
Video | Aspeed AST2600 |
Storage Technology | 2 x M.2 22110/2280/2260 slots (PCI-E 3.0 x4) 1 x microSD slot 6 x MCIO x8 Connectors 12 x SATA 6Gb/s Ports Backplane: 6 x MCIO x8, 3 x SlimSAS x4 |
Connectivity | 1 x Realtek RTL8211F Management LAN Port (ASMB12-iKVM) |
Expansion | 3 x PCI-E 5.0 x16 slots or 6 x PCI-E 5.0 x16 slots (x8 link) (FHFL) Note: No GPU Supports 2 x PCI-E 5.0 x16 slots (Full Height, Half Length) 2 x OCP 3.0 slot (PCI-E 5.0 x16) |
Rear I/O | DC-SCM Board: 1 x Power Button with LED 1 x RJ45 GbE Management LAN 2 x USB 3.2 (Gen1) 1 x Mini DisplayPort 1 x Location Button with LED 1 x USB 3.2 (Gen1) Type-C |
Front Panel I/O | 2 x USB 3.2 (Gen1) 1 x Power Button with LED 1 x ID with LED 2 x Status LED (Message, LAN) 1 x Reset Switch |
Drive Support | 2 x M.2 22110/2280/2260 slots (PCI-E 3.0 x4) 8 x 3.5"/2.5" NVMe/SATA Hot Swap Bays 4 x 3.5"/2.5" NVMe Hot Swap Bays |
Power Supply | 1+1 Redundant 2700W 80 PLUS Titanium PSU 100-127V~/220-240V~, 12A/16A (x2), 50/60Hz |
Cooling | 6 x Middle Case Fans |
Case Dimensions | 2U Rackmount 822.16 x 484.65 x 87.3mm 32.37" x 19.08" x 3.44" (in inches) |
Environmental | Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) Non-Operating Humidity: 20% to 95% (non-condensing) |
Compliance | BSMI, CE, CB, RCM, FCC (Class A), ISED |
Warranty | 3 Year Manufacturer's Limited Warranty |
