Manufacturer	ASUS
Product ID	RS720-E11-RS12U-26W10G
Model Number	RS720-E11-RS12U
CPU	Supports 2 x 5th/4th Gen Intel Xeon Scalable Processors, Emerald Rapids Socket LGA 4677
Chipset	Intel C741
Memory	32 x DDR5 DIMMs (16 per CPU) 4800/4400 MHz Maximum 4TB RDIMM Capacity Maximum 8TB RDIMM 3DS Capacity
Video	ASPEED AST2600
Storage Technology	Backplane: Supports NVMe/SATA/SAS Tri-Mode Note: SAS Support Requires HBA/RAID Card 12 x SATA 6Gb/s Connectors Intel VROC: Support Software RAID 0, 1, 10 & 5, 50 2 x SlimSAS x8 Connectors 2 x M.2: PCI-E 4.0 x4
Connectivity	2 x Intel X710-AT2 GbE LAN 1 x Realtek RTL8211F Management Port
Expansion	3 x PCI-E 5.0 x16 (Full Height, Full Length) or 6 x PCI-E 5.0 x8 slots (Full Height, Half Length) 1 x PCI-E 5.0 x16 (Full Height, Full Length) or 2 x PCI-E 5.0 x8 slots (Full Height, Half Length) Note: Maximum Length 285mm 1 x PCI-E 5.0 x16 (Half Height, Half Length)
Rear I/O	1 x Power Button with LED 1 x Port 80/Q-Code 1 x Location Button with LED 1 x VGA 1 x RJ45 Management LAN 2 x USB 3.2 (Gen1) 4 x RJ45 GbE LAN
Front Panel I/O	2 x USB 3.2 (Gen1) 1 x Power Button with LED 1 x Reset Switch 1 x Location Button with LED 5 x Status LED (LAN, Message)
Drive Support	12 x 3.5"/2.5" Hotswap NVMe/SATA Drive Bays Note: SAS Support Requires HBA/RAID Card 2 x M.2 2280/2260 slot (PCI-E 4.0 x4)
Power Supply	1+1 1600W 80-PLUS Platinum Power Supply 100-127Vac / 220-240Vac, 10A/8A (x2), 50/60Hz
Cooling	4 x System Fans
Case Dimensions	2U Form Factor 840 x 447 x 88mm 33.07" x 17.60" x 3.46" (in inches) Includes Rail Kit
Environmental	Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) Non-operating Humidty: 20% to 90% (non-condensing)
Compliance	BSMI, CE, CB, FCC (Class A)
Warranty	1 Year Manufacturer's Limited Warranty
