| Manufacturer | ASUS |
| Product ID | RS700-E12-RS12U-2KW10G |
| Model Number | RS700-E12-RS12U |
| CPU | Supports 2 x Intel Xeon 6 Processors Socket LGA 4710 |
| Chipset | SoC |
| Memory | 32 x DDR5 DIMM slots (16 per CPU) Maximum up to 4TB Capacity 5600/6400 RDIMM (1DPC/2DPC) 8000 MCR RDIMM (1DPC) 8-Channel per CPU |
| Video | Aspeed AST2600 |
| Storage Technology | 2 x M.2 2280/2260 slots (PCI-E 4.0 x2) 8 x MCIO x8 Connectors Backplane: 6 x MCIO x8, 3 x SlimSAS x4 |
| Connectivity | 1 x Management LAN Port (ASMB12-iKVM) |
| Expansion | 2 x PCI-E 5.0 x16 slots (Full Height, Half Length) 1 x OCP 3.0 slot (PCI-E 5.0 x16) 1 x OCP 3.0 slot (PCI-E 5.0 x8) |
| Rear I/O | DC-SCM Board: 1 x Power Button with LED 1 x RJ45 GbE Management LAN 2 x USB 3.2 (Gen1) 1 x Mini DisplayPort 1 x Location Button with LED 1 x USB 3.2 (Gen1) Type-C |
| Front Panel I/O | 1 x Power Button with LED 5 x Status LED (Message, LAN) 1 x Location Switch with LED 1 x Reset Switch |
| Drive Support | 2 x M.2 2280/2260 slots (PCI-E 4.0 x2) 12 x 2.5" NVMe Hot Swap Bays Note: SATA/SAS Support requires HBA/RAID Card |
| Power Supply | 1+1 Redundant 2000W 80 PLUS Platinum PSU 100-127V~/220-240V~, 12A/10A (x2), 50/60Hz |
| Cooling | 8 x 40x56mm Middle Case Fans |
| Case Dimensions | 1U Rackmount 449 x 43.85 x 800mm 17.68" x 1.73" x 31.5" (in inches) |
| Environmental | Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) Non-Operating Humidity: 20% to 95% (non-condensing) |
| Compliance | BSMI, CE, CB, RCM, FCC (Class A), ISED |
| Warranty | 3 Year Manufacturer's Limited Warranty |
PRODUCT ID: RS700-E12-RS12U-2KW10G
