| Manufacturer |
ASUS |
| Product ID |
RNUC15JNK7X5000U |
| Model Name |
NUC15JNK |
| CPU |
Intel Core Ultra 7 255HX Processor
8 P-Cores / 12 E-Cores / 20 Threads
1.8 - 5.2 GHz
45W-160W TDP, 30 MB Cache, 36 MB L2 Cache
|
| Chipset |
Integrated
Firmware TPM (Intel PTT)
|
| Memory |
2 x DDR5 CSODIMM/SODIMM slots
Maximum 96GB Capacity
SODIMM supports 5600 MHz
CSODIMM supports 6400 MHz
Dual Channel |
| Video |
NVIDIA GeForce RTX 5060 Laptop GPU
Dynamic Boost 8GB GDDR7
Intel Graphics
300 MHz - 1.85GHz
8 GPU Peak TOPS (Int8)
4 Xe-Cores
Thunderbolt 4 Max Resolution: 3840x2160@30Hz
DisplayPort 2.1 Max Resolution: 3840x2160@144Hz
HDMI (FRL) Max Resolution: 3840x2160@144Hz
Single DisplayPort Max Resolution: 7680x4320@60Hz
Supports up to Five 4K Displays
|
| Audio |
Realtek ALC3251 HD Audio
|
| Storage Technology |
1 x M.2 2280 slot (PCI-E 5.0 x4)
1 x M.2 2280 slot (PCI-E 4.0 x4)
|
| Connectivity |
Intel E3100G 2.5GbE LAN
Killer WIFI 7 BE1750x (Gig+)
802.11be
Bluetooth 5.4
|
| Expansion Slots |
1 x Thunderbolt 4 Port
|
| Rear Panel I/O |
4 x USB 3.2 (Gen1)
1 x RJ45 2.5GbE LAN
1 x USB4 Type-C (Thunderbolt 4)
2 x DisplayPort
2 x HDMI
1 x 19.5V DC IN
|
| Front Panel I/O |
1 x Power Button with LED
1 x 3.5mm Audio I/O
1 x USB 3.2 (Gen1) Type-C
2 x USB 3.2 (Gen1)
|
| Drive Support |
1 x M.2 2280 slot (PCI-E 5.0 x4)
1 x M.2 2280 slot (PCI-E 4.0 x4)
|
| OS Support |
Windows 11 Pro 64-bit
Windos 11 IoT Enterprise 64-bit
Ubuntu 24.04 LTS 64-bit
RedHat Enterprise Linux 64-bit
|
| Power Supply |
19.5V DC-IN
330W Adapter
|
| Case Dimensions |
282.4 x 187.7 x 56.5mm
11.11" x 7.39" x 2.22" (in inches)
|
| Mounting |
Stand
|
| Environmental |
Operating Temperature: 0°C to 35°C (32°F to 95°F)
|
| Warranty |
3-Year Manufacturer's Limited Warranty |
