Model Number	R5
CPU Support	Supports Intel LGA 2011/2066 Square ILM 165 TDP Max Recommended for 2U Servers
Connection	4 Pin (PWM)
Voltage	12V
Speed	At Duty Cycle 20%: 1700 RPM At Duty Cycle 50%: 4000 RPM At Duty Cycle 100%: 8500 RPM
Performance	At Duty Cycle 20%: 8.85 CFM At Duty Cycle 50%: 21.97 CFM At Duty Cycle 100%: 46.44 CFM
Volume	At Duty Cycle 20%: 21.8 dBA At Duty Cycle 50%: 34.5 dBA At Duty Cycle 100%: 52.8 dBA
Dimensions	91.5 x 91.5 x 66.0 mm 3.61" x 3.61" x 2.60" (in inches)
Fan Dimensions	60 x 60 x 25 mm 2.36" x 2.36" x 0.99" (in inches)
Weight	590g
Features	Shin-Etsu G751 Thermal Grease
