Manufacturer	Dynatron
Model Number	R24
CPU Support	Supports Intel LGA2011/LGA2066 (Narrow Type, 56 x 95mm Mounting Pitch) 165W TDP MAX
Rated Voltage	12V
Input Power	At Duty Cycle 20%: 0.6 W At Duty Cycle 50%: 1.68 W At Duty Cycle 100%: 9.60 W
Speed	At Duty Cycle 20%: 1300 RPM At Duty Cycle 50%: 3500 RPM At Duty Cycle 100%: 7000 RPM
Static Pressure:	At Duty Cycle 20%: 0.57 mm-H2O  At Duty Cycle 50%: 3.57 mm-H2O At Duty Cycle 100%: 14.3 mm-H2O
Maximum Airflow:	At Duty Cycle 20%: 8.1 CFM At Duty Cycle 50%: 20.26 CFM At Duty Cycle 100%: 40.53 CFM
Noise Level	At Duty Cycle 20%: 17.0 dBA At Duty Cycle 50%: 31.9 dBA At Duty Cycle 100%: 51.2 dBA
Connector	4-pin PWM
Dimensions	112 x 84 x 67 mm  4.4" x 3.3" x 2.64" (in inches)
Fan Size	60mm x 60mm x 28mm
Features	Shin-Etsu  7762 Thermal Compound (pre-printed)
