| Manufacturer | GigaIPC |
| Product ID | QS-N150A |
| CPU |
Intel® Processor N150 Intel® 7, 4 Cores Up to 3.60 GHz 6W TDP |
| Chipset | SoC |
| Memory |
1 x DDR5 SO-DIMM Slot Maximum 16GB Capacity Single Channel DDR5 4800 MHz |
| Video |
Intel® UHD Integrated Graphics 3 x HDMI 2.0: Max Resolution 4096x2160 @60Hz HDMI 1 & 2 Support CEC Supports 3 Independent Displays |
| Audio | Realtek® ALC269 |
| Storage |
1 x M.2 2280 M-Key (PCIe Gen 3x1 / SATA 6Gb/s) 1 x Micro SD Card Slot (USB 2.0) |
| Connectivity | 2 x Realtek® RTL8111H GbE LAN |
| Expansion Slots |
1 x M.2 2230 E-Key (WiFi/BT) 1 x M.2 3042 B-Key with SIM Slot (3G/4G LTE) |
| Front Panel I/O |
2 x USB 3.2 Gen 1 1 x HDMI 2.0 1 x COM Port RS-232 (RJ45 Type) 1 x Micro SD Card Slot 1 x Power Button |
| Rear Panel I/O |
2 x HDMI 2.0 2 x RJ45 GbE LAN Ports 2 x USB 3.2 Gen 1 1 x Combo Audio Jack (Headphone & Headset) 1 x DC Jack |
| Side I/O | 3 x External Antenna Holes (Optional) |
| OS Support |
Windows 10 Windows 11 |
| Power Supply |
+12V~19V DC Input 19V / 65W AC-DC Adapter Included 100-240VAC |
| Case Dimensions |
165 x 105 x 27mm 6.50" x 4.13" x 1.06" (in inches) |
| Mounting | Includes VESA Mount Bracket and Screws |
| Environmental |
Operating Temperature: 0°C to 50°C (32°F to 122°F) Non-Operating Temperature: -40°C to 85°C (-40°F to 185°F) Operating Humidity: 50°C @ 20-95% (non-condensing) Non-Operating Humidity: 85°C @ 95% (non-condensing) Operating Vibration: IEC 60068-2-64, 3 Grms, random, 5 ~ 500 Hz, 1 hr / Per Axis, With SSD Non-Operating Vibration: IEC 60068-2-6, 2 G, Sine, 10 ~ 500 Hz, 1 Oct/min, 1 hr / Per Axis Operating Shock: IEC 60068-2-27, 50 G, half sine, 11 ms duration, With SSD |
| Warranty | 1-Year Warranty on Parts and Labor |
PRODUCT ID: QS-N150A
