| Manufacturer |
Mitac |
| Part Number |
PD11EHI-J6413 |
| CPU |
Intel Celeron J6413 Processors
4 Cores / 4 Threads
1.80 - 3.00 GHz
10W TDP, 1.5 MB L2 Cache
|
| Chipset |
SoC |
| Memory |
2 x DDR4 SODIMM slots
Maximum 32GB Capacity
3200 MHz
|
| Video |
Intel UHD Graphics
400 - 800 MHz
HDMI Max Resolution: 4096x2160@30Hz
DisplayPort Max Resolution: 4096x2160@60Hz
|
| Audio |
Realtek ALC888 HD Audio
|
| Storage Technology |
1 x SATA3 6.0Gb/s Connector
1 x M.2 2280/2242 slot (SATA3, PCIe x2)
Supports NVMe SSD
|
| Connectivity |
2 x Realtek RTL8111G GbE LAN
|
| Expansion Slots |
1 x M.2 2230 slot (PCIe/USB 2.0, M Key)
|
| Power |
1 x 24-Pin ATX Power Connector
|
| Rear I/O |
1 x DisplayPort
2 x COM (RS232)
2 x HDMI
2 x RJ45 GbE LAN
2 x USB 3.1 (Gen2)
2 x USB 2.0
3 x Audio I/O
|
| Onboard I/O Headers |
3 x USB 2.0 headers (Supports 5 Ports)
1 x Stereo Speaker header
1 x Audio header (Front Panel Mic in and Line out)
1 x 4-Pin CPU Fan header
1 x 4-Pin System Fan header
1 x AT/ATX jumper
1 x Buzzer
1 x MiAPI header
|
| Form Factor |
Mini ITX
6.7" x 6.7"
170 x 170mm
|
| Environmental |
Operating Temperature: 0°C to 60°C (32°F to 140°F)
Non-Operating Temperature: -40°C to 85°C (-40°F to 185°F)
Operating Humidity: 10% to 95% (Non-Condensing)
|
| Compliance |
CE, FCC Class B, UKCA
|
| Warranty |
1-Year Manufacturer's Limited Warranty |
