Model Number	NDL-AR150DMX500
CPU	Intel Celeron J1900 2.00 - 2.42GHz 4 Cores / 4 Threads 10W TDP, 2MB Cache, 64-bit
Chipset	SoC
Memory	2 x 204-pin DDR3 SODIMM Maximum 8GB capacity 1333MHz Minimum
Video	Intel Gen7 Intel Graphics DX 11, OGL3.2 VGA Max Resolution: 1920x1200 HDMI 1.3a Max Resolution: 1920x1200 LVDS Max Resolution: 1920x1200@60Hz Supports Dual Display
Audio	2 x Audio In/Out
Storage	1 x mSATA 2 x 2.5" SATA Drive Note: SATA_2 shared with mSATA
Connectivity	2 x Realtek RTL8111G-CG 10/100/1000 (Gigabit)
Expansion Slots	1 x PCI Express x1 (2.0) 1 x Mini PCI-E slot (Half length)
Rear Panel I/O	1 x HDMI 2 x PS/2 Keyboard/Mouse 3 x COM Ports 1 x VGA 2 x RJ45 LAN 2 x USB 2.0 2 x USB 3.0 2 x Audio I/O
Front Panel I/O	1 x Power Button with LED 2 x USB 2.0
Drive Support	1 x mSATA 1 x 2.5" SATA Drive or 2 x 2.5" SATA Drive
Power Supply	80W 12V DC-DC Power Board (Internal) 60W 12V Efficiency Level VI AC-DC Adapter (External)
Case Dimensions	228.4mm x 194.4mm x 61.8mm 9" x 7.7" x 2.5"
Case Cooling	2 x 40mm x 10mm
Mounting	Wallmount Bracket Optional VESA Mounting Bracket
Warranty	1-Year Warranty on Parts and Labor
