| Product ID | MWS-WRX80-DXL |
| CPU | AMD 3rd Generation Threadripper Pro Processor AMD Socket sWRX8 4094 Supports 280W TDP Liquid Cooled |
| Chipset | AMD WRX80 |
| Memory | 8 x 288-pin DDR4 DIMM slots Maximum 1024GB Capacity 32000/2933/2600MHz 8-Channel Memory Architecture Supports Non-ECC UDIMM, ECC UDIMM, RDIMM, 3DS RDIMM, and LDIMM |
| Video | GPU Dependent |
| Audio | Realtek ALC1200-VB Codec 7.1 Channel High Definition Audio Supports S/PDIF Out |
| Storage Technology | 4 x SATA3 6Gb/s Ports Support Software RAID 0, 1, 5, 10 2 x M.2: PCI-E 4.0 x4 and SATA Mode 2 x slimSAS: PCI-E 4.0 x4 or 4x SATA 1 x slimSAS: PCI-E 4.0 x4 |
| Connectivity | 2 x Intel X550 10GbE LAN 2 x Intel i210AT GbE LAN |
| Expansion Slots | 6 x PCI-E 4.0 x16 slots 1 x PCI-E 4.0 x8 slot |
| Rear Panel I/O | 1 x VGA 1 x Serial Port 5 x USB 3.2 (Gen2) Type-A 1 x USB 3.2 (Gen2) Type-C 2x RJ45 GbE LAN 2 x RJ45 10GbE LAN 5 x Audio I/O 1 x S/PDIF Out |
| Front Panel I/O | 1 x Power Button 1 x Reset Button 2 x USB 3.0 2 x Audio I/O 1 x USB 3.1 Type-C 1 x ARGB Control Button (M: Mode, C: Color) 2 x USB 3.0 |
| Drive Support | 1TB NVMe M.2 Solid State Drive Installed 4TB 3.5" 7200PRM Enterprise SATA Hard Drive Installed 6 x 2.5" Drive Bays 4 x 3.5"/2.5" Drive Bays |
| Cooling | 3 x 120mm/2 x 140mm (Base) (Occupied by Radiator) 1 x 120mm Case Fan (Rear) Supports 3 x 120mm/2x 140mm (Top) Supports 3 x 120mm (Side) |
| OS Software | Ubuntu 18.04 LTS NVIDIA CUDA, TensorFlow, Caffe2, PyTorch, Mxnet, DL4J, Docker, Keras |
| Power Supply | 1600W 80+ Gold Power Supply 115-240V, 17-9A, 50-60Hz |
| Case Dimensions | 18.5" x 11.2" x 20.2" (in inches) 471 x 285 x 513mm |
| Warranty | 1-Year Warranty on Parts and Labor |
PRODUCT ID: MWS-WRX80-DXL
