| Product ID | MES-N97TIMA |
| CPU | Intel N97 Processor 4 Cores / 4 Threads 3.60 GHz 12W TDP, 6 MB Intel Smart Cache |
| Chipset | SoC |
| Memory | 1 x DDR5 SODIMM slot Maximum 16GB Capacity 4800 MT/s Supports non-ECC, unbuffered memory Support In-Band ECC Technology (using non-ECC memory) |
| Video | Intel UHD Graphics 1.2 GHz 24 Execution Units HDMI Max Resolution: 4096 x 2160@60Hz VGA Max Resolution: 4096 x 2160@60Hz |
| Audio | Realtek ALC 897 HD Audio Codec |
| Storage Technology | 2 x SATA3 6Gb/s Connector (SATA port 2 shared with M.2 ) 1 x M.2 2280 slot (PCIe 3.0 x2/SATA) |
| Connectivity | 2 x Realtek 8111H 1GbE LAN |
| Expansion Slots | 1 x M.2 2242/2260/2280 M-Key (PCIe x2 or SATA) 1 x M.2 2230 E-Key (Supports PCIe 3.0 x1 and USB 2.0 WIFI/BT Adapters) |
| Rear Panel I/O | 1 x 12V DC-IN 2 x RJ45 1GbE LAN 2 x USB 2.0 2 x USB 3.2 Gen1 1 x DP 1 x HDMI 1 x Audio I/O |
| Front Panel I/O | 2 x USB 2.0 1 x Power Button with LED |
| Drive Support | 2 x 2.5" SATA Drive Bays 1 x M.2 2280 slot (PCIe 3.0 x2/SATA) Note: SATA Port 2 Shared with M.2 |
| OS Support | Windows 10 64-bit Windows 11 64-bit Linux |
| Power Supply | 9V-36V DC-IN 60W 12V AC/DC Adapter |
| Case Dimensions | 228.6mm x 195.6mm x 63.5mm 9" x 7.7" x 2.5" (in inches) |
| Cooling | Supports 4 x 40mm Case Fans |
| Mounting | Wall Mounting Brackets Optional Secure VESA Mounting Bracket (see options) |
| Warranty | 1-Year Warranty on Parts and Labor |
