| Manufacturer | Intel |
| Product ID | M50FCP1UR212 |
| Model Name | M50FCP |
| CPU | Supports 2 x Intel 4th Gen Xeon Scalable Processor Socket LGA 4677 Maximum 205W TDP |
| Chipset | Intel C741 |
| Memory | 32 x DDR5 DIMM slots (16 per CPU) Supports up to 4TB ECC RDIMM per CPU Dual Channel |
| Video | Aspeed AST2600 |
| Storage Technology | 16 x PCIe MCIO Connectors 2 x 4-Port Mini-SAS HD (SFF-8643) Connectors 2 x M.2: PCIe/SATA Supports Intel Virtual RAID on CPU (Intel VROC) RAID 0, 1, 5, 10 |
| Connectivity | 1 x GbE Dedicated Management LAN |
| Expansion | 2 x PCI-E 5.0 x16 (Low Profile, Half Length) 1 x PCI-E 5.0 x8 (Low Profile, Half Length) 1 x OCP 3.0 slot (PCI-E 5.0 x16) |
| Rear I/O | 1 x VGA 1 x RJ45 GbE LAN 1 x RJ45 Serial Port 2 x USB 2.0 Ports 1 x System ID Button with LED 1 x USB 3.0 Port |
| Front Panel I/O | 1 x USB 2.0 1 x USB 3.0 1 x Power Button with LED 1 x Reset Button (Tool Required) 1 x System ID Button with LED 1 x NMI Button (Tool Required) 2 x Status LED (System Status, Drive LED) |
| Drive Support | 12 x 2.5" NVMe/SATA Hotswap Drive Bays 2 x M.2 2280/22110 slot (PCI-E 3.0 x4, SATA) |
| Power Supply | No Power Supply Included Optional 1300W/1600W 80-PLUS Titanium Power Supply Optional 1+0 (Single Power), 1+1 Redundant, 2+0 Combined Power (No Redundancy) 90-140V (Rated 100-127V) and 180-264V (Rated 200-240V) 47-63Hz (Rated 50/60Hz) |
| Cooling | 8 x 40x56mm Case Fans |
| Case Dimensions | 1U Rackmount 767 x 438.5 x 43mm 30.2" x 17.3" x 1.7" (in inches) |
| Environmental | Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) |
| Warranty | 3 Year Manufacturer's Limited Warranty |
PRODUCT ID: M50FCP1UR212
