| Manufacturer |
InWin |
| Part Number |
RS208-07-CR800.OL.R |
| Motherboard Support |
ATX (12" x 9.6") CEB (12" x 10.5") EEB (12" x 13") |
| Drive Support |
8 x 3.5"/2.5" Hotswap Drive Bays 3 x 2.5" Internal Drive Bays 1 x ODD 2 x 2.5" Rear Hotswap Bays |
| Backplane |
2 x Mini-SAS HD (SFF-8643) Connectors 4 x OCuLink (SFF-8611) Connectors Supports 4 x SATA/SAS and 4 x NVMe/SATA/SAS
Rear: 1 x Mini-SAS HD (SFF-8643) Connector Supports 2 x SATA/SAS |
| Fan |
4 x 80x38mm 12000RPM PWM Hotswap Fans |
| Expansion Slots |
7 x PCI Slots (Low Profile)
|
| Front Panel |
1 x Power Switch 1 x ID Switch 1 x System Reset 1 x NMI 2 x USB 3.0 6 x Status LED (Power, HDD, LAN, System Fail) |
| Power Supply |
800W 1+1 80+ Platinum CRPS Redundant Power Supply |
| Case Dimensions |
660 x 448 x 87.5mm 26" x 17.6" x 3.4" (in inches) |
| Mounting |
Supports 28" tool-less Ball Bearing Slide Rail |
| Warranty |
1-Year Manufacturer's Limited Warranty |
