Manufacturer	Mitac
Product ID	G4520G6U2BC-N
Model Number	G4520G6
CPU	Supports 2 x Intel Xeon 6 Processors Socket LGA 4710 Maximum 350W TDP
Chipset	SoC 2 x Broadcom PEX89104 PCI-E 5.0 switch
Memory	32 x DDR5 DIMM slots RDIMM/RDIMM-3DS 6400/5200MHz MRDIMM 8000 (1DPC) -P Core Only Maximum 8192GB Capacity 8-Channel
Video	Aspeed AST2600
Storage Technology	3 x M.2 2280/22110 slots (PCI-E 4.0 x4) Backplane: 8 x NVMe
Connectivity	1 x Realtek RTL8211F GbE LAN (Dedicated IPMI)
Expansion	11 x PCI-E 5.0 x16 slot (Full Height, Full Length) 3 x OCP 3.0 Mezzanine slots (PCI-E 5.0 x16)
Rear I/O	1 x RJ45 GbE Dedicated IPMI LAN 2 x USB 3.0
Front Panel I/O	2 x USB 3.2 (Gen1) 1 x VGA 1 x Reset Button 1 x UID Button 5 x Status LED (Power, ID, HDD, System Event) 1 x Power Button 1 x COM
Drive Support	3 x M.2 2280/22110 slots (PCI-E 4.0 x4) 8 x 2.5" NVMe Hotswap Bays
Power Supply	3+1 9600 Watt 80-Plus Titanium CRPS 200-240V/16A, 50/60Hz
Cooling	4 x 80x38mm Middle Fans 4 x 80x38mm Rear Fans
Case Dimensions	4U Rackmount 32.78" x 17.62" x 6.9" (in inches) 832.6 x 447.4 x 176mm
Environmental	Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Operating Humidity: 90% at 35°C (non-condensing) Non-Operating Humidity: 90% at 35°C (non-condensing)
Compliance	FCC (SDoC) Class A CE (DoC) Class A CB RCM VCCI BSMI NRTL RoHS 6/6 Compliant RoHS 2.0 Compliant
Warranty	3 Year Manufacturer's Limited Warranty
