Manufacturer	ASUS
Product ID	ESC8000-E12
Model Number	ESC8000-E12
CPU	Supports 2 x Intel Xeon 6 Series Processors Socket LGA 4710 Up to 350W TDP
Chipset	SoC
Memory	32 x DDR5 RDIMM slots (16 DIMMs per CPU) Maximum 4TB Capacity 6400 (1DPC) / 5200 (2DPC) RDIMM
Video	Aspeed AST2600 64MB
Storage Technology	2 x M.2 22110/2280 slots (PCI-E 5.0 x4) Backplane: 4 x MCIO Connectors (x8 link), 2 x SlimSAS Connectors (x4 link) PCIe switch: 4 x MCIO Connectors (x8 link)
Connectivity	1 x Management Port
Expansion	8 x PCI-E 5.0 x16 slot (Full Height, Full Length) 1 x PCI-E 5.0 x16 slot (Full Height, Half Length) 2 x PCI-E 5.0 x16 slot (x8 link, Full Height, Half Length)
Rear I/O	1 x USB 3.2 (Gen1) 1 x Location Button with LED 1 x MSG LED 1 x Power Button with LED 1 x RJ45 Management LAN
Front Panel I/O	1 x Q-Code/Port 80 LED 1 x Mini DisplayPort 1 x Debug Port 2 x USB 3.2 (Gen1) 1 x MSG LED 1 x Location Button with LED 1 x Power Button with LED 1 x Clear CMOS switch 1 x Reset switch
Drive Support	8 x 2.5" Hotswap Drive Bays (Requires HBA/RAID Card)
OS Support	Windows Server RedHat Enterprise Linux SuSE Linux Enterprise Server CentOS Ubuntu VMWare
Power Supply	3+1 3200W 80 Plus Titanium Power Supply 220-240Vac, 16A (x4), 50/60Hz
Cooling	5 x System Fans 5 x GPU Fans
Case Dimensions	4U Rackmount 31.5" x 17.3" x 6.9" 800 x 438.5 x 175mm Net Weight: 42 kg Gross Weight: 44.23 kg
Environmental	Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) Non-Operating Humidity: 20% to 95% (non-condensing)
Compliance	BSMI, CB, CE, FCC (Class A), RCM
Warranty	3 Year Manufacturer's Limited Warranty
