Manufacturer | ASUS |
Product ID | ESC NB8-E11 |
Model Number | ESC-NB8-E11 |
CPU | Supports 2 x Intel 5th/4th Gen Xeon Scalable Processors Emerald Rapids Socket LGA 4677 Up to 350W TDP |
Chipset | Intel C741 |
Memory | 32 x DDR5 RDIMM / 3DS RDIMM slots Maximum 4TB per CPU 4400 MHz 8-Channel per CPU |
Video | Aspeed AST2600 64 MB |
Storage Technology | Backplane Connectors: 4 x EXAMAX, 1 x MCIO, 1 x Mini SAS HD 1 x MCIO Connector 1 x Mini SAS HD 2 x M.2 2280 slots (PCI-E 3.0 x2) |
Connectivity | 2 x Intel X710-AT2 10G LAN 1 x Management Port |
GPU | 8 x NVIDIA Blackwell HGX B200 with NVLink Switch 180GB HBM3E GPU Memory |
Expansion | 8 x PCI-E 5.0 x16 slots (Low Profile, Half Length, PCIe switch) 2 x PCI-E 5.0 x16 slots (Full Height, Half Length) 1 x PCI-E 4.0 x8 slot (Full height Half Length) for RAID Cards |
Rear I/O | 1 x Location Button with LED 1 x Power Button with LED |
Front Panel I/O | 2 x RJ45 10G LAN 1 x RJ45 Management LAN 1 x Location Button 1 x Q-Code/Port-80 LED 1 x VGA 4 x USB 3.2 (Gen1) 1 x Power Button with LED |
Drive Support | 8 x 2.5" Hotswap Bays (8 x NVMe) 2 x 2.5" Hotswap Bays (Rear) (SATA) |
OS Support | Redhat Enterprise Linux Rocky Linux Ubuntu VMWare |
Power Supply | 5+1 Redundant 3000W 80 PLUS Titanium Power Supply 200-220 Vac, 15.8A (x6), 50-60Hz |
Cooling | 15 x GPU Fans |
Case Dimensions | 10U Rackmount 885 x 447 x 435.95mm 34.8" x 17.6" x 17.16" (in inches) Net Weight: 121 kg Gross Weight: 173 kg |
Environmental | Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Non-Operating Humidity: 20% to 90% (non-condensing) |
Compliance | BSMI, CB, CE, FCC, KCC (Class A) |
Warranty | 3 Year Manufacturer's Limited Warranty |
