Manufacturer	Tyan
Product ID	B7126G68V4E4HR
CPU	Supports 2 x Intel Xeon 3rd Gen Scalable Processor Socket LGA4189 Supports up to 205W TDP Note: 205W TDP requires airduct and ambient temperature 30°C
Chipset	Intel C621A
Memory	16 x DDR4 DIMM slots (8 per CPU) Supports up to 2,048GB ECC RDIMM/LRDIMM 3200MHz 8-Channel per CPU
Video	Aspeed AST2500
Storage Technology	Mini-SAS HD (4 SATA Ports) Supports RAID 0/1/10/5 (Intel RSTe) 4 x NVMe Ports from M1312G68-BP6E-4X Card Supports Intel VROC 1 x M.2: PCIe Interface
Connectivity	2 x Intel I210 GbE LAN 1 x Realtek RTL8211E Dedicated IPMI
Expansion	2 x PCI-E 4.0x16 slots (Full Height, Full Length) 1 x PCI-E 3.0 x16 OCP v2.0 Mezzanine slot
Rear I/O	1 x RJ45 Dedicated IPMI 2 x USB 3.0 1 x VGA 1 x COM Port 2 x RJ45 GbE LAN
Front Panel I/O	1 x USB 3.0 1 x Power Button with LED 1 x ID Button
Drive Support	4 x 2.5" NVMe Drive Bays 4 x 3.5" SATA Drive Bays 1 x M.2 22110/2280 slot (PCIe Interface)
Power Supply	1+1 Redundant 850W 80 Plus Platinum RPSU 100-240V, 12-6A, 47-63Hz
Cooling	6 x 40x56mm Fans
Case Dimensions	1U Form Factor 26.77" x 17.26" x 1.69" (in inches) 680 x 438.5 x 43mm
Environmental	Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Operating Humidity: 90% (non-condensing) Non-operating Humidty: 90% (non-condensing)
Compliance	FCC (SDoC) Class A CE (DoC) Class A CB/LVD RCM Class A VCCI Class A RoHS 6/6 Compliant
Warranty	1 Year Manufacturer's Limited Warranty
