Product ID | SYS-5019P-MT |
CPU | Single Socket P (LGA 3647) Intel Xeon Scalable Processors Maximum TDP: 205W Up to 28 Cores |
Chipset | Intel C622 |
Memory | 8 x DIMM slots Up to 1TB ECC 3DS LRDIMM, 256GB ECC RDIMM 2666/2400/2133MHz DDR4 SDRAM |
Video | ASPEED AST2500 BMC |
Storage Technology | 4 x SATA3 (6Gbps); RAID 0, 1, 5, 10 |
Connectivity | Dual 10GBase-T LAN with Intel® X772 + X557 Dedicated IPMI Port |
Management | IPMI 2.0 with virtual media over LAN and KVM-over-LAN support |
Expansion | 1 PCI-E 3.0 x16 (FHFL) slot |
Rear I/O | 1 x Serial 1 x IPMI RJ45 2 x USB 2.0 2 x USB 3.0 2 x 10GbE RJ45 1 x VGA |
Front I/O | Power On/Off button System Reset button Power LED Hard drive activity LED Network activity LEDs System Overheat LED |
Drive Support | 4 x 3.5" SATA 6.0Gb/s 1 x M.2 NVMe 2 x SATA Disk On Module(s) 1 x Slim Optical Drive Bay Supports 4 x 2.5" drives using appropriate adapter. |
Power Supply | 350W Power Supplies with PFC 100 ~ 240V Operation 80 PLUS Platinum Certified |
Case Dimensions | 43 x 437 x 503mm 1.7" x 17.2" x 19.8" (in inches) |
Case Cooling | 4 x 40x28mm PWM Fans |
Mounting | Standard 19" 1U Rackmount Two sets of rail assemblies, mounting brackets and mounting screws are included. |
Warranty | 1-Year Warranty on Parts and Labor |
