Manufacturer	ASRock Rack
Product ID	2U2G-TURIN
CPU	Supports AMD EPYC 9005/9004 Processors (with AMD 3D V-Cache Technology) Supports 97x4 Series Processors Socket SP5 Up to 500W TDP
Chipset	SoC
Memory	12 x DDR5 DIMM slots Max Capacity per RDIMM: 128GB Max Capacity per RDIMM-3DS: 256GB 6400 MHz
Video	Aspeed AST2600
Storage Technology	2-port NVMe Passive backplane 2 x M.2 22110/2280/2260 slots (PCI-E 5.0 x4 or SATA)
Connectivity	1 x Realtek RTL8211F GbE Dedicated Management LAN
Expansion	2 x PCE-E 5.0 x16 slots (Full Height, Full Length, Dual Slot) Note: Supports GPU up to 350W 1 x PCI-E 5.0 x16 slot (Half Height, Half Length) 1 x OCP 3.0 slot (PCI-E 5.0 x16)
Rear I/O	1 x COM 1 x VGA 1 x RJ45 GbE LAN 2 x USb 3.2 (Gen1)
Front Panel I/O	3 x Status LED (HDD, System Event LED) 2 x USB 3.2 (Gen1) 1 x Power Button 1 x UID Button 1 x Reset Button
Drive Support	2 x 2.5" NVMe (PCI-E 4.0 x4) Bays 2 x M.2 22110/2280/2260 slots (PCI-E 5.0 x4 or SATA)
Power Supply	1+1 80-PLUS Titanium CRPS 100-127Vac: 1000W Output 200-240Vac: 2000W Output 50/60Hz Note: Full Redundancy May not be supported with 100-127V Input. Redundancy support depends on total system power consumption relative to single PSU Capacity
Cooling	4 x 80x56mm Hotswap Front PWM Fans 1 x 40x28mm Fixed PWM Fan
Case Dimensions	2U Rackmount 580 x 438 x 87mm 22.8" x 17.2" x 3.4" (in inches)
Environmental	Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Non-Operating Humidity: 20% to 95% (non-condensing)
Warranty	1 Year Manufacturer's Limited Warranty
