| Manufacturer | ASRock Rack |
| Product ID | 1U2N2G-AM5/2T |
| Model Number | 1U2N2G-AM5/2T |
| CPU |
Per Node: Supports AMD EPYC 4005/4004 Series Processors Supports AMD Ryzen 9000/8000/7000 Series Processors Socket AM5 Max 120W TDP |
| Chipset | KNOLL3 X300 |
| Memory |
Per Node: 4 x DDR5 DIMM slots ECC/Non-ECC UDIMM 48GB Max Capacity per DIMM 5600 MHz (1DPC), 3600 MHz (2DPC) |
| Video | Aspeed AST2600 |
| Storage Technology |
Per Node: 1 x M.2 2280 slot (PCI-E 4.0 x4) |
| Connectivity |
Per Node: 2 x Broadcom BCM57416 10G LAN 1 x Realtek RTL8211F GbE Dedicated IPMI |
| Expansion |
Per Node: 1 x PCI-E 5.0 x16 slot (FH, FL) or 2 x PCI-E 5.0 x8 slot (FH, FL) Support Maximum GPU Dimensions: 266.7 x 111.15 x 39.04mm |
| Rear I/O | N/A |
| Front Panel I/O |
Per Node: 2 x RJ45 10G LAN 1 x HDMI 1 x VGA 1 x RJ45 GbE Dedicated IPMI 2 x USB 3.0 1 x UID Button 1 x Power Button with LED |
| Drive Support |
1 x M.2 2280 slot (PCI-E 4.0 x4) Per Node |
| OS Support |
Windows 10 (64-Bit) / Windows 11 (64-Bit) Ubuntu 22.04.2 (64-bit) |
| Power Supply |
1+1 80-PLUS Platinum CRPS 100-127Vac Input: 1000W 200-240Vac Input: 1600W 60/50 Hz |
| Cooling |
8 x 40x56mm Case Fans |
| Case Dimensions |
1U Rackmount 650 x 438 x 43.5mm 25.6" x 17.2" x 1.7" (in inches) |
| Environmental |
Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Non-Operating Humidity: 20% to 90% at 35°C (non-condensing) |
| Warranty | 1 Year Manufacturer's Limited Warranty |
PRODUCT ID: 1U2N2G-AM5/2T
