Manufacturer	ASRock Rack
Product ID	1U12E-TURIN2/EVAC
CPU	Supports 2 x AMD EPYC 9005/9004 (with AMD 3D V-Cache Technology) Processors Supports 2 x 97x4 Series Processors Socket SP5 Up to 360W (Conditionally Supported)
Chipset	SoC
Memory	24 x DDR5 DIMM slots (12 per CPU) Max Capacity per RDIMM: 128GB (2Rx4) Max Capacity per RDIMM-3DS: 256GB (2Rx4) 6400 MHz
Video	Aspeed AST2600
Storage Technology	Backplane: 12-port NVMe (PCI-E 5.0 x4) Passive 1 x M.2 2280/2260/2242/2230 slot (PCI-E 3.0 x4) 1 x M.2 2280/2242 slot (PCI-E 3.0 x4)
Connectivity	2 x Intel i350 GbE LAN 1 x Realtek RTL8211F GbE Dedicated Management LAN
Expansion	2 x PCI-E 5.0 x16 (Full Height, Half Length) 1 x OCP 3.0 slot (PCI-E 5.0 x16)
Rear I/O	1 x VGA 1 x RJ45 COM 1 x RJ45 GbE Dedicated Management LAN 1 x UID Button with LED 2 x RJ45 GbE LAN 2 x USB 3.2 (Gen1)
Front Panel I/O	1 x USB 3.2 (Gen1) 1 x Power Button with LED 1 x Reset Button 1 x NMI Button 1 x ID Button with LED 4 x Status LED (HDD, LAN, System Fault)
Drive Support	12 x 2.5" NVMe Drive Bays 1 x M.2 2280/2260/2242/2230 slot (PCI-E 3.0 x4) 1 x M.2 2280/2242 slot (PCI-E 3.0 x4)
Power Supply	1+1 80-PLUS Platinum CRPS 100-127Vac: 1000W 200-240Vac: 2000W 50/60 Hz Note: Full redundancy may not be supported with low-line input. Redundancy support depends on total system power consumption relative to single PSU capacity
Cooling	8 x 40x56mm Easy-swap Fans
Case Dimensions	1U Rackmount 830 x 438 x 43.5 mm 32.7'' x 17.2'' x 1.7'' (in inches)
Environmental	Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Non-Operating Humidity: 20% to 95% (non-condensing)
Warranty	1 Year Manufacturer's Limited Warranty
