| Manufacturer | Supermicro |
| Product ID | SYS-110P-FRN2T |
| CPU |
Supports Intel 3rd Gen Xeon Scalable Processors LGA 4189 Supports up to CPU TDP 85-205W |
| Chipset | Intel C621A |
| Memory |
8 x DDR4 DIMM slots Supports ECC RDIMM/LRDIMM 3200 MHz |
| Video | ASPEED AST2600 BMC |
| Storage Technology |
10 x SATA3 Ports RAID 0, 1, 5, 10 M.2: PCI-E 3.0 x4 and SATA |
| Connectivity |
2 x Intel X550-AT2 10G LAN 1 x Realtek RTL8221FS-VS-CG Dedicated IPMI LAN |
| Expansion |
2 x PCI-E 4.0 x16 slot (Full Height, Full Length) |
| Rear I/O |
5 x Hotswappable Fans |
| Front Panel I/O |
5 x Status LED (Power, HDD, LAN, BMC) 1 x Reset Button 1 x Power Button 1 x Serial Port 1 x RJ45 GbE Dedicated IPMI 2 x USB 2.0 2 x USB 3.2 2 x RJ45 10G LAN 1 x VGA |
| Drive Support |
2 x 2.5" Drive Bays 1 x M.2 22110/2280 slot (M Key, PCI-E 3.0x4/SATA) |
| Power Supply |
800W 80 PLUS Platinum Redundant Power Supply with PMBus AC Input: 100-127Vac 50-60Hz, 200-240Vac 50-60Hz DC Input: 230-240Vdc +12V Max: 62.5A / Min: 0A (100Vac-127Vac) +12V Max: 66.6A / Min: 0A (200Vac-240Vac) +12V Max: 66.6A / Min: 0A (230Vdc-240Vdc) 5V SB Max: 4A / Min: 0A |
| Cooling |
5 x 40x56mm 13K-11K RPM Hotswappable Fans |
| Case Dimensions |
1U Form Factor 15.7" x 17.2" x 1.7" (in inches) 399 x 437 x 43mm |
| Environmental |
Operating Temperature: 0°C to 40°C (32°F to 104°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Operating Humidity: 8% to 90% (non-condensing) Non-operating Humidty: 5% to 95% (non-condensing) |
| Warranty | 1 Year Manufacturer's Limited Warranty |
PRODUCT ID: SYS-110P-FRN2T
