Manufacturer |
ASUS |
Model Name |
PN51-S1 |
Product ID |
PN51-S1-BB5000XTD |
CPU |
AMD Ryzen 5 5500U Processor 6 Cores / 12 Threads 2.1 - 4.0 GHz 15W TDP, 3MB L2 Cache, 8MB L3 Cahce
|
Chipset |
SoC TPM Module On board
|
Memory |
2 x DDR4 SODIMM slots Maximum 16GB Capacity Up to 3200MHz Non-ECC, Unbuffered Memory Only |
Video |
AMD Radeon Vega Graphics 7 Graphic Cores 1800 MHz Supports Triple Display via HDMI, DisplayPort, USB-C Supports Single 8K Display via DisplayPort Dual-Mode (DP++) Note: Requires DP++ Compatible Device
|
Audio |
Realtek ALC897 HD Audio |
Storage Technology |
1 x SATA3 6.0Gb/s Port 1 x M.2: PCI-E 3.0 x4
|
Connectivity |
1 x Realtek RTL8125B-CG 2.5GbE LAN WIFI 6 Bluetooth 5.0
|
Rear Panel I/O |
1 x HDMI 1 x DisplayPort 1 x USB 3.2 (Gen1) Type-C with DP Output 1 x RJ45 2.5GbE LAN 2 x USB 3.2 (Gen1) Type-A 1 x 19V DC-IN
|
Front Panel I/O |
1 x Audio Out 1 x USB 3.2 (Gen1) Type-C 1 x USB 3.2 (Gen1) Type-A 1 x Power Button 1 x HDD LED
|
Drive Support |
1 x 2.5" SATA Drive Bay 1 x M.2 2280 slot (PCI-E 3.0 x4)
|
OS Support |
Windows 10 Home / Pro Windows 11 Home / Pro
|
Power Supply |
19V DC-IN 90W 19V Power Adapter |
Case Dimensions |
115 x 115 x 49mm 4.5" x 4.5" x 1.9" (in inches, approximate) |
Mounting |
VESA Mount |
Environmental |
Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Operating Humidity: 8% to 90% (non-condensing) Non-operating Humidty: 5% to 95% (non-condensing) |
Compliance |
BSMI/CB/CE/FCC/UL/CCC/Energy Star/C-Tick/WiFi/RF/VCCI |
Warranty |
1-Year Warranty on Parts and Labor |
