Product ID | HPW-B560NR200 |
CPU | Supports Intel 10th/11th Gen Core Processors Socket LGA1200 Supports Intel Turbo Boost Max 3.0 Technology |
Chipset | Intel B560 |
Memory |
Includes 16GB DDR4 Memory 2 x DDR4 DIMM slots Maximum 64GB Capacity 11th Gen Core i9/i7/i5 supports 3200MHz Natively 10th Gen Core i9/i7 supports 2933MHz Natively 10th/11th Gen Core i3, Pentium, Celeron support 2666MHz Natively Non-ECC, Unbuffered Memory Only Supports Intel Extreme Memory Profile (XMP) 2.0 |
Video | GPU Dependent |
Audio | Realtek ALC897 Audio Codec 7.1 CH HD Audio |
Storage Technology | 4 x SATA3 6.0 GB/s Ports Supports Intel Rapid Storage Technology 18 1 x M.2: SATA and PCI-E 4.0 x4 (11th Gen) or PCI-E 3.0 x4 (10th Gen) Note: M.2 SATA shared with SATA3_0 |
Connectivity | 1 x Intel I219V PHY GbE LAN Supports Wake-On-LAN Supports PXE Intel 802.11ac WIFI Dual Band (2.4/5 GHz) Bluetooth 4.2 + High speed class II |
Expansion Slots | 1 x PCI-E 4.0 x16/PCI-E 3.0 x16 slot (CPU dependent) 1 x Vertical M.2 (E-Key, Occupied by WIFI) |
Rear Panel I/O | 1 x HDMI 1 x DisplayPort 1 x PS/2 2 x USB 3.0 1 x RJ45 GbE LAN 2 x USB 2.0 2 x Antenna Connectors 3 x Audio I/O |
Top Panel I/O | 1 x Power LED 2 x USB 3.2 (Gen1) Type-A 1 x Power Button 1 x 3.5mm Headset Jack (Audio, MIC) |
Drive Support |
Includes 1TB M.2 NVMe SSD 2 x 3.5" Drive Bays 1 x 3.5"/2.5" Drive Bay 2 x 2.5" Drive Bays 1 x M.2 2280 slot (SATA or NVMe) |
Cooling | Rear: 1 x 92mm PWM Case Fan Top: Supports 2 x 120mm Bottom: Supports 2 x 120mm Side: Supports 2 x 120/140mm |
Power Supply | 700W 80 Plus Gold Power Supply with Active PFC 100-240Vac, 50-60Hz |
Case Dimensions | 376 x 185 x 292mm 14.8" x 7.2" x 11.5" (in inches) |
Warranty | 1-Year Warranty on Parts and Labor |
